ProductS Recovery Winches

IRB-W4600

Max. Working Pressure 150 Bar
Pump Flow 60 lt/min
Rope Diameter 10 mm
Max Rope Capacity 50 m.
Motor Displacement 80 cc.
Brake Multidisc Brake
Free Pulling
Gear Train Planetary Gear

Rope Winding Layer n 1 2 3 4 5
Pulling Capacity daN 4600 3850 3320 2960 2740
Rope Winding Speed m/min 12.3 14.9 20.6 23.2 25.9
Total Rope on the drum m. 6.8 15.1 24.9 36.2 50.0

PERFORMANCE CHARTS AT THE 1ST LAYER
